TECHNICAL DETAILS
-
Length X Width X Height
1980×835×1075mm
-
Wheelbase
1370mm
-
Seat height
790mm
-
Tank capacity
13L
-
Curb weight
153kg
-
Ground clearance
139mm
-
Engine type
In-line dual cylinder/DOHC/4-stroke/Water-cooled
-
Displacement
249cc
-
Bore x stroke
62×41.4mm
-
Max. power
24kW @ 11500rpm
-
Max. torque
22.5N.m @ 9000rpm
-
Compression Ratio
12.5:1
-
Max. speed
160km/h
-
Frame type
Diamond shape, dual-wing beam, integrated
-
Front suspension
Φ37mm upside down damping, YUAN
-
Front Brake
320mm single disc, 2-piston calliper/ABS
-
Rear Brake
220mm single disc, 1-piston calliper/ABS
-
Front Tire
110/70 R17
-
Rear Tire
140/60 R17
-
Steering Angle
40°
-
Rake Angle
24.5°
-
Instrumention
TFT
